Our fully automatic gypsum powder grinding plant features low energy consumption, uniform particle size and reliable operation, providing a cost-effective turnkey solution for industrial gypsum processing.
Item No :
gypsum grinding preparation systemOrder(MOQ) :
1Payment :
NegotiationProduct Origin :
ChinaColor :
CustomizeShipping Port :
China PortsLead Time :
NegotiationWeight :
Based on actualComplete Industrial Gypsum Grinding Equipment Line
Our gypsum grinding preparation system is a professional, integrated production line designed for processing natural gypsum, desulfurization gypsum (FGD gypsum) and phosphogypsum into high-quality gypsum powder. With advanced technology, stable performance and energy-saving design, it solves the core pain points of low efficiency, uneven fineness and high energy consumption for industrial gypsum processing, becoming the preferred choice for construction, building materials and chemical industries worldwide.
Product Overview
The gypsum powder grinding plant integrates crushing, grinding, classifying, drying and packaging into one complete system, which can be customized according to your raw material type, output demand and powder fineness (200-1250 mesh). It adopts intelligent control system, realizing automatic operation, reducing labor cost and ensuring consistent product quality. Whether you need a small-scale production line or a large turnkey project, we can provide a tailor-made solution to meet your actual production needs.
Core Advantages
• High Efficiency & Energy Saving: Advanced vertical roller mill or Raymond mill reduces energy consumption by 20-30% and improves grinding efficiency by 40%.
• Stable & Easy Maintenance: High-quality wear-resistant materials, simple operation, and long service life of key components minimize downtime.
• Precise Fineness Control: High-precision classifier ensures uniform particle size, adjustable for 200 mesh, 325 mesh, 800 mesh, 1250 mesh, etc.
• Eco-Friendly & Safe: Professional dust collection equipment minimizes emissions and meets international environmental standards.
• Turnkey & Customized: One-stop service from design to after-sales, tailored to your raw materials, output, and budget.
Technical Parameters (non-metallic minerals, chemical industry, etc.)
|
Model specification |
HVM800X |
HVM1250X |
HVM1300X |
HVM1500X |
HVM1700X |
HVM1900X |
HVM2400X |
HVM2800X |
|
|
Capacity |
1~3 t/h |
2~7 t/h |
3~10 t/h |
4~15 t/h |
6~22 t/h |
7.5~25 t/h |
9~38 t/h |
11~45 t/h |
|
|
Grinding material moisture |
≤5% |
||||||||
|
Product fineness |
（10~40um）97% |
||||||||
|
Product moisture |
≤1% |
||||||||
|
Main Motor Power |
55 kW |
132 kW |
180 kW |
250 kW |
355/400 kW |
450 kW |
560/630 kW |
710 kW |
|
|
Description |
Note: 1. The above technical indicators are based on materials with Mohs hardness of 3~4. |
||||||||
Vertical Grinding System Process
Raw materials are elevated into a silo, then fed into a vertical roller mill for grinding and drying. Qualified fine powder is separated via a classifier and cyclone, while coarse powder returns for regrinding. Exhaust gas is purified by a bag filter before emission. Finished powder is stored in a silo, ready for packaging or dispatch.
Project Cases
 |
 |
|
★ Project Name: GYPMAN TECH COMPANY LIMITED 20–25 TPH Vertical Mill Gypsum Powder Preparation System
|
|
FAQ – Gypsum Grinding Preparation System
1. What materials can your gypsum grinding system process?
Our system is specially designed for grinding gypsum and gypsum-based materials, suitable for natural gypsum, synthetic gypsum (FGD gypsum), phosphogypsum, desulfurization gypsum, and other materials with similar grindability.
2. What capacity and fineness can your system achieve?
For gypsum powder processing, the system capacity ranges from 15 to 150 tons per hour (or an annual output of 100,000 to 1,000,000 tons). The finished gypsum powder fineness can be adjusted between 80 mesh and 1250 mesh to meet different application requirements such as gypsum board, plaster of paris, building mortar, and cement retarder.
3. How do I choose the right system model?
Our engineers will recommend the most suitable model based on your raw material type (natural gypsum, FGD gypsum, phosphogypsum), required capacity, target fineness, raw material moisture content, application scenario (gypsum board plant, plaster production, cement plant, etc.), and site conditions.
4. What is the difference between a vertical mill and a ball mill for gypsum grinding?
Compared with a ball mill, our vertical mill offers higher grinding efficiency (20%–30% increase), lower energy consumption (30%–50% reduction), larger capacity, smaller footprint, better environmental performance (less dust and noise), and easier maintenance—making it the ideal choice for modern gypsum powder production lines.
5. Can you provide customized gypsum grinding solutions?
Yes, we provide customized design and manufacturing based on your specific requirements, including capacity, fineness, material type, site layout, and special conditions such as high-moisture FGD gypsum.
6. Do you offer a complete gypsum powder production line?
Yes, we provide turnkey solutions covering the entire gypsum grinding process, including crusher, bucket elevator, feeder, vertical mill, dust collector, control system, and product storage or packaging equipment.
7. What installation and after-sales services do you provide?
We offer on-site guidance for installation and commissioning, operator training, long-term supply of wear-resistant spare parts, and 24/7 online technical support to ensure stable operation.
8. What is the delivery time?
Delivery time is approximately 90–120 working days for standard models, and around 120 working days for customized production lines.
9. What control system does your gypsum grinding system use?
The system is equipped with an advanced PLC automatic control system with a touch screen interface, enabling intelligent and unmanned operation of feeding, grinding, classifying, and drying, with remote monitoring and fault alarm functions.
10. Do your products have certifications?
Yes, our gypsum vertical mill systems meet international industrial standards and hold certifications such as CE and ISO, ensuring quality, safety, and environmental compliance for global export.
11. Looking for a reliable gypsum grinding system?
If you are seeking a high-quality, energy-efficient, and cost-effective solution for gypsum powder production for gypsum board, plaster, building mortar, cement retarder, or other industrial applications, contact us today.
We provide:
- Free quotation
- Customized solutions
- Detailed technical parameters and catalogs
- On-site installation, commissioning, and after-sales support
Contact us now to get the best price and professional support for your gypsum grinding project!
